46C1577 002，CAB WIRING AS, LIUGONG PARTS CATALOGUES
| 46C1577 002 驾驶室线路总成 CAB WIRING AS | |||||
|---|---|---|---|---|---|
| 件号 ITEM |
部件号 PART NO. | 版本 VER |
零件名称 | PART NAME | 数量 Q'TY |
| 1 | 32J0003 | 001 | 工作灯 | WORK LIGHT | 4 |
| 2 | 32B0158 | 001 | 旋转信号灯 | ROTATING BEACON | 1 |
| 3 | 11A2339 | 001 | 旋转灯安装板 | MOUNTING PLATE |
1 |
| 4 | 04B0221 | 000 | 螺钉 | SCREW | 3 |
| 5 | 06B0066 | 000 | 垫圈 | WASHER | 5 |
| 6 | 06B0361 | 000 | 垫圈 | WASHER | 5 |
| 7 | 00B0075 | 000 | 螺栓 | BOLT | 4 |
| 8 | 06B0005 | 000 | 垫圈 | WASHER | 4 |
| 9 | 03B0021 | 000 | 螺母 | NUT | 2 |
| 10 | 06B0348 | 000 | 垫圈 | WASHER | 4 |
| 11 | 37B0314 | 001 | 水管接头 | CONNECTOR | 1 |
| 12 | 46C2233 | 000 | 前雨刮器总成 | FRONT WIPER AS | 1 |
| 13 | 08C1380 | 000 | 旋转灯线束 | HARNESS | 1 |
| 14 | 83A0165 | 001 | 护孔圈 | GROMMET | 3 |
| 15 | 08C2020 | 001 | 雨刮线束 | HARNESS | 1 |
| 16 | 37B0442 | 000 | 后窗雨刮控制器 | WIPER CONTROLLER | 1 |
| 17 | 00B0335 | 000 | 螺栓 | BOLT | 2 |
| 18 | 08C1487 | 002 | 顶灯线束 | HARNESS | 1 |
| 19 | 46C6166 | 000 | 继电器总成 | RELAY AS | 1 |
| 20 | 00B0012 | 000 | 螺栓 | BOLT | 2 |
| 21 | 06B0001 | 000 | 垫圈 | WASHER | 2 |
| 22 | 06B0347 | 000 | 垫圈 | WASHER | 2 |
| 23 | 46C6130 | 000 | 电器集中控制盒 | CONTROL BOX | 1 |
| 24 | 46C2278 | 003 | 开关面板总成 | PLATE | 1 |
| 25 | 06B0024 | 000 | 垫圈 | WASHER | 11 |
| 26 | 00B0022 | 000 | 螺栓 | BOLT | 11 |
| 27 | 06B0346 | 000 | 垫圈 | WASHER | 11 |
| 28 | 46C2234 | 000 | 后雨刮器总成 | REAR WIPER AS | 1 |
| 29 | 37B0335 | 001 | 喷头 | NOZZLE | 1 |
| 30 | 37J0006 | 000 | 前清洗水管 | HOSE | 2 |
| 31 | 37B0460 | 000 | 两通 | CONNECTOR | 2 |
| 32 | 83A0131 | 000 | 护孔圈 | GROMMET | 3 |
| 33 | 06B0097 | 000 | 垫圈 | WASHER | 10 |
| 34 | 06B0352 | 000 | 垫圈 | WASHER | 10 |
| 35 | 04B0099 | 000 | 螺钉 | SCREW | 10 |
| 36 | 38B0065 | 001 | 扬声器 | LOUDSPEAKER | 2 |
| 37 | 46C2279 | 001 | 收音机总成 | RADIO AS | 1 |
| 38 | 32B0151 | 001 | 壁灯 | DOME LIGHT | 1 |
| 39 | 34J0001 | 000 | 制动开关 | BRAKE SWITCH | 1 |
| 40 | 37B0369 | 001 | 天线 | ANTENNA | 1 |
| 41 | 83H0001 | 000 | 护孔圈 | GROMMET | 5 |
| 42 | 08C4870 | 000 | 驾驶室线束 | HARNESS | 1 |
| 43 | 37B0004 | 001 | 尼龙扎带 | NYLON STRAP | 16 |
| 44 | 46C1595 | 002 | 前仪表台总成 | INSTRUMENT PANEL | 1 |
